AJAZZ India · Magnetic Gaming Series

AJAZZ AK680 V3

Magnetic Competitive Dual-Light Position — a high-performance gaming magnetic switch keyboard with a carbon fiber body, Rapid Trigger precision and dual ARGB lighting.

192K SCAN RATE 0.001mm STEP RT 8K POLLING 0.08ms LATENCY DUAL ARGB HOT-SWAPPABLE

192K Ultra-High Scanning Rate

0.001mm Step RT Precision

8K Feedback Rate

0.08ms Approx. Latency

AK680 V3 Music Rhythm 2.0 and carbon fiber body

At a glance

Built to Be Seen, Felt and Tuned

Fully self-developed Music Rhythm 2.0 — rhythm can be seen, rhythm can be felt. Add high-end keys, a dedicated RT key and a carbon fiber body.

High-End Keys SOCD, RS, TGL, MT and DKS.

RT Keys Press one key to switch between four modes.

Carbon Fiber Body Stable, deformation-resistant, tough and flexible integrated structure.

Dual-Light Positions 16 million-color RGB lighting effects.

Carbon Fiber Body

Triple Empowerment

Carbon fiber shell, FR4 and TOP mount structure combine for a stable, anti-deformation and resilient build for more stable and precise keystrokes.

Forged Carbon Pattern Keycaps Tough, scratch-resistant and designed to resist grease.

Multi-functional Rotary Knob Adjust volume and switch onboard profiles.

Full Configuration Filling

Hi-Fi Handfeel and Sound

Layered internal filling helps reduce noise resonance for a satisfying typing feel and sound.

Top Forged carbon keycaps, carbon fiber shell and Thunder Crystal magnetic switches.

Plate & Foam Aluminum alloy plate, gasket foam, IXPE switch pad and PET foam.

Base PCBA, bottom foam and bottom silicone.

Extras Metal rotary knob, ambient light cover and forged carbon bottom case.

*This is a rendering. Please refer to the actual product.

AK680 V3 Thunder Shadow and Thunder Crystal magnetic switches

Flagship Customization

Full Hot-Swappable Support

Millisecond-level actuation with magnetic drive for fast response. The aluminum alloy plate provides stronger support and crisp keystroke feedback.

Thunder Shadow Switch POM switch with frosted translucent white finish. Initial force 30±5GF · Initial flux 95±15GS · Bottom-out force 55±5GF · Bottom-out flux 580±50GS · Lifespan 100 million+ keystrokes.

Thunder Crystal Switch Clear switch made from PC material. Initial force 30±5GF · Initial flux 98±15GS · Bottom-out force 55±5GF · Bottom-out flux 580±50GS · Lifespan 100 million+ keystrokes.

AK680 V3 0.001mm precision and 8K polling

Brutal Performance

Dominate the Arena

Stable 0.001mm precision with ultra-low latency, an ultra-high scanning rate and a high polling rate for competitive gaming.

0.08ms Ultra-low latency.

192K Ultra-high scanning rate.

8K Ultra-high polling rate.

0.005–3.6mm Rapid Trigger range and actuation travel.

Music Engine 2.0

Visualize the Rhythm, Feel the Beat

Supports customizable lighting, screen synchronization, music rhythm effects, game integration and multiple built-in presets.

AK680 V3 dynamic lighting and side ambient lighting

Dual ARGB Light Positions

Dynamic and Ambient Lighting

Dynamic Lighting System Customizable lighting effects.

Side Ambient Lighting Enhances your desktop setup.

Customizable Dynamic Key Travel

RS Rapid trigger-style functionality binds two selected keys and activates the key pressed deeper.

SOCD Binds two selected keys and activates them according to your chosen settings.

TGL A single tap toggles continuous activation on or off. Holding the key performs its normal function.

MT Assigns two functions to one key: one action when held and another when tapped.

DKS Enables one key to perform up to four different functions based on four different actuation depths.

Web & PC Dual Drivers

One-Touch Web Driver Activation

Long press FN + ESC for 5 seconds to launch the web driver. Customize keys, macros, lighting and performance. Configure SOCD, MT, TGL and other features for office, esports and creative modes.

OPEN WEB DRIVER ↗

https://hj.sparklinkplayjoy.com/v2/device

AK680 V3 cross-platform web driver compatibility

macOS users: Due to macOS system restrictions, the web driver cannot be opened using key combinations. Enter the URL manually or visit the AJAZZ official website. Use a browser with HID support, such as Google Chrome. The default macOS browser may not be supported.

Multicolor Colorway

Pick Your Style

Pink, black, white and carbon fiber-inspired looks with a range of keycap styles. Scheme: Star Flash Sparkle.

Keycap Options OEM side-printed · White and pink two-tone frosted transparent.

OEM side-printed · Black translucent carbon fiber texture.

OEM black translucent · Neon iridescent.

OEM white · Side-printed frosted transparent.

White multicolor top-printed frosted transparent.

Periodic table · Top-printed transparent.

Full Specifications

AJAZZ AK680 V3

Product Model	AK680 V3 Magnetic Switch
Connection Type	Wired connection (keyboard and cable separate).
Scheme	Star Flash Sparkle.
Switch Assembly	Thunder Shadow Magnetic Switch / Thunder Crystal Magnetic Switch.
Hot-Swappable	Supports mixed magnetic switches; compatible with TTC Magneto King and other N-pole downward magnetic switches.
Structure	TOP mount structure.
Positioning Plate	Aluminum alloy.
PCB	FR4 plate.
Rapid Trigger Accuracy	0.001mm step.
Rapid Trigger Range	0.005–3.6mm.
Actuation Travel	0.005–3.6mm.
Matrix Scan Rate	192K.
Polling Rate	8K.
Latency	Approximately 0.08ms.
Internal Filling	PO foam + IXPE switch pad + PET foam + EPDM foam + silicone.
Backlight	Dual ARGB light positions.
Driver	Web and PC dual drivers.
Dimensions	351.2 × 128.9 × 42.01mm (front height: 20mm).
Weight	Approximately 700g.
Package Contents	Wrist rest / lanyard + dust cover + 2-in-1 switch and keycap puller + manual + two magnetic switches.

Case Variants

Tail	Bottom Housing	Top Case
Pink (Standard)	ABS injection molding (Pink)	Non-carbon fiber / Pink (ABS + PC + Fiberglass)
Black (Standard)	ABS injection molding (Black)	Carbon fiber composite / Black (ABS + PC + Carbon Fiber)
White (Standard)	ABS injection molding (White)	Non-carbon fiber / White (ABS + PC + Fiberglass)
Black (Standard)	ABS injection molding (Black)	Carbon fiber composite / Black (ABS + PC + Carbon Fiber)
